Plant Trailers
Tri-Axle Plant Trailers
Tri axle tag trailer for hire from $495 per day.
Hire conditions apply. Minimum 2 days hire. Bond required.
ATM
0
T
GTM
0
T
Length
0
m
SPECIFICATIONS
Dimensions & Capacity
ATM: 28T
GTM: 20T
Tare Weight: Approx. 7T
Total Length: 10.9m Overall
Deck Length: 8.74m
Construction & Frame
Mainframe: High-tensile steel grade
Floor: 5mm steel chequered plate, forklift-rated
Coupling: Pintle hook
Coaming: C-channel with tie rail
Tie-down Points: Integrated into the floor
Brake Kit: EBS multi-volt 12/24V
Axles, Suspension & Running Gear
Axles: K-Hitch 22.5” drum brake axles
Suspension: K-Hitch tri-axle FUWA FW520 8-leaf spring
Landing Legs: K-Hitch 2-speed
Wheels:10/285 PCD dual steel rims
Tyres: 255/70R22.5
Spare Wheel Carrier: Single
Lighting & Electrical
Lighting: Full LED
Equipment & Accessories
Toolboxes: 2 steel with stainless steel “T” handles
Container Pins: 20ft
Mudguards:Alloy quarter guards front and rear with AAA Trailers mudflaps
Ramps:
Bi-fold with 12V electric power pack
N150 battery
Built-in Anderson plug
(Lay-flat ramps optional)
Bi-fold with 12V electric power pack
N150 battery
Built-in Anderson plug
(Lay-flat ramps optional)
Optional Extras
Custom paint – coaming rails
Hard-wired flashing beacon
Hub odometer
Spare wheel: steel or alloy
Hard-wired flashing beacon
Hub odometer
Spare wheel: steel or alloy
